Dell Latitude D420 - Manual (Page 54)

Replacing the Hard Drive
1. Follow the steps in Removing the Hard Drive in reverse order.
2. Install the operating system for your computer (see Restoring Your Operating System ").
3. Install the drivers and utilities for your computer (see Reinstalling Drivers and Utilities ).
Hinge Cover
1. Follow the procedures in Before You Begin .
2. Open the display all the way (180 degrees) so that it rests on your work surface.
3. Starting on the right side of the computer, use a plastic scribe to pry up the hinge cover.
1 ZIF connector 2 hard drive cable
NOTICE: Use firm and even pressure to slide the drive into place. If you use excessive force, you may damage the connector.
NOTE: This computer is not equipped with an optical drive—use the Media Base (sold separately) to install software.
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface (such
as a connector on the back of the computer).
NOTICE: The hinge cover is fragile and can be damaged if extreme force is used. Be careful when removing the hinge cover.
NOTICE: To avoid damaging the hinge cover, do not lift the cover on both sides simultaneously.
1 hinge cover 2 plastic scribe
