Statement of Volatility –
Dell E6230/E6330/E6430/E6430ATG/E6530
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
The Dell Latitude™ E6230/E6330/E6430/E6430ATG/E6530 contains both volatile and non-volatile (NV)
components. Volatile components lose their data immediately after power is removed from the component.
Non-volatile (NV) components continue to retain their data even after power is removed from the
component. The following NV components are present on the
Dell Latitude™ E6230/E6330/E6430/E6430ATG/E6530 system board.
Table 1. List of Non-Volatile Components on System Board
Description
Reference
Designator
Volatility Description
User
Accessible
for
external
data
Remedial Action (Action
necessary to prevent loss of
data)
Embedded
Flash in
embedded
controller
MEC5055 U51 256K and 2K byte of
embedded Flash memory for
embedded controller BIOS
code, asset tag, and BIOS
passwords. No N/A
Panel EEDID
EEPROM
Part of LCD
panel
assembly Non-volatile memory
64K bytes. Stores panel
manufacturing information
and display configuration
data. No N/A
System BIOS U52,U53
Non-volatile memory,
64Mbit (8 MB), 32Mbit (4 MB)
System BIOS and Video BIOS
for basic boot operation, PSA
(on board diags), PXE diags. No N/A
System
Memory –
DDR3
memory
Connectors
JDIMMA and
JDIMMB Volatile memory in OFF state
(see state definitions later in
text). One or both modules
will be populated. System
memory size will depend on
SoDIMM modules and will be
between 1 GB to 8 GB. Yes Power off system
System
memory
SPD
EEPROM On memory
SoDIMM(s) –
one or two
present Non-volatile memory 2Kbit
(256 bytes). One device
present on each SoDIMM.
Stores memory
manufacturer data and
timing information for
correct operation of system
memory. No N/A
