Removing the display latch – Dell Latitude D820 User Manual
Page 15
6.
Remove the four screws from the left display-panel side bracket and lift away the bracket.
Removing the Display Latch
1.
Follow the instructions in
Before Working Inside Your Computer
.
2.
Remove the display assembly (see
).
3.
).
4.
Remove the display panel (see
5.
Remove the four screws from the top display-panel bracket and lift away the bracket.
6.
Slide the display latch toward the right side of the top cover and straight out.
7.
Unhook the latch spring from the display latch, and then lift away the latch.
1
display panel
2
display-panel side bracket
3
screws (4)
CAUTION:
Before performing the following procedures, follow the safety instructions in the Product Information Guide.
CAUTION:
To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of
your computer's electronic components. You can do so by touching an unpainted metal surface.
1
screws (4)
2
top display-panel bracket
3
top cover
1
display latch
2
latch spring
