Dell Precision M4700 (Mid 2012) - Manual (Page 71)

Table 21. Expansion Bus
Feature Specification
Bus Type PCI 2.3, PCI Express 1.0 and 2.0, SATA 1.0A ,2.0 and 3.0, USB 2.0 and 3.0
Bus Width PCIe X16
BIOS Chip (NVRAM) 96 Mb (12 MB)
Table 22. Ports and Connectors
Feature Specification
Audio two connectors for line-out and line-in/microphone
Network Adapter one RJ45 connector
USB 2.0 two
USB 3.0 two
eSATA\USB 2.0 one
IEEE1394:
M4700 one 4–pin IEEE 1394 connector
M6700 one 6–pin IEEE 1394 connector
Video 15-pin VGA connector, 19-pin HDMI connector, 20-pin DisplayPort
connector
Memory card reader one 8-in-1 memory card reader
Docking port one
Subscriber Identity Module (SIM) port one
ExpressCard one
Smart card (optional) one
Table 23. Display
Feature M4700 M6700
Type
• HD (1366 X 768)
• FHD (1920 X 1080)
• HD+ (1600 X 900)
• FHD (1920 X 1080)
Size 15.6 inches 17.3 inches
Dimensions:
Height 256 mm (10.07 inches) 270.60 mm (10.65 inches)
Width 376 mm (14.80 inches) 416.70 mm (16.40 inches)
Diagonal 396.24 mm (15.60 inches) 439.42 mm (17.3 inches)
Active area (X/Y) 344.23 mm X 193.54 mm
• 382.08 mm X 214.92 mm (HD+)
• 381.89 mm X 214.81 mm (FHD)
71
