Environmental Characteristics

Power Management Modes

If you have VESA's DPM™ compliance display card or software installed in your PC, the monitor can automatically reduce its power consumption when not in

use. This is referred to as Power Save Mode*. If the computer detects input from keyboard, mouse, or other input devices, the monitor automatically resumes

functioning. The following table shows the power consumption and signaling of this automatic power saving feature:

^^Based on measurement of standby power consumption using VGA input

The OSD will only function in the normal operation mode. When the menu or plus buttons are pressed in Active-off mode, one of the following messages will be

displayed:

Analog Input In Power Save Mode. Press Computer Power Button or Any Key on Keyboard or Move Mouse

OR

Digital Input In Power Save Mode. Press Computer Power Button or Any Key on Keyboard or Move Mouse

Activate the computer and the monitor to gain access to the OSD.



* Zero power consumption in OFF mode can only be achieved by disconnecting the main cable from the monitor.

Pin Assignments

VGA Connector

Weight without stand assembly
(For wall mount or VESA mount considerations -
no cables)

8.86 lb (4.02 kg)

Weight of stand assembly

3.63 lb (1.65 kg)

Model

G2410H

Temperature



Operating

5° to 35°C (41° to 95°F)

Non-operating

Storage: -20° to 60°C (-4° to 140°F)
Shipping: -20° to 60°C (-4° to 140°F)

Humidity



Operating

10% to 80% (non-condensing)

Non-operating

Storage: 5% to 90% (non-condensing)
Shipping: 5% to 90% (non-condensing)

Altitude



Operating

3,657.6 m (12,000 ft) max

Non-operating

12,192 m (40,000 ft) max

Thermal dissipation

98.977 BTU/hour (maximum)
68.26 BTU/hour (typical)

VESA Modes

Horizontal Sync

Vertical Sync

Video

Power Indicator

Power Consumption

Normal operation

Active

Active

Active

Blue

20 W (typical)/29 W (maximum)

Active-off mode

Inactive

Inactive

Blanked

Amber (breathing)

0.15 W^^

Switch off

-

-

-

Off

Less than 0.15 W

NOTE:

This monitor is ENERGY STAR®-compliant as well as TCO '03 power management compatible.
