Dell G2410 Monitor - Manual (Page 5)

Bottom View
Monitor Specifications
Flat Panel Specifications
* G2410H color gamut (typical) is based on CIE1976 (80%) and CIE1931 (68%) test standards.
Resolution Specifications
Video Supported Modes
Bottom view
Label Description
1 AC power cord connector
2 DVI connector
3 VGA connector
Model G2410H
Screen type Active matrix - TFT LCD
Panel type TN
Screen dimensions 24 inches (24-inch viewable image size)
Preset display area:
Horizontal 531.36 mm (20.92 inches)
Vertical 298.89 mm (11.77 inches)
Pixel pitch 0.277 mm
Viewing angle 160° (vertical) typ, 170° (horizontal) typ
Luminance output 250 cd/m ²(typ)
Contrast ratio 1000 to 1 (typ)
Dynamic contrast ratio Up to 1,000,000 : 1 (typ)
Faceplate coating Antiglare with hard-coating 3H
Backlight W-LED system
Response Time 5ms typical
Color gamut (Typical) 80%*
Model G2410H
Horizontal scan range 30 kHz to 83 kHz (automatic)
Vertical scan range 56 Hz to 75 Hz (automatic)
Maximum resolution 1920 x 1080 at 60 Hz
