Preset Display Modes
Electrical Specifications
Physical Characteristics
Model G2410H
Video display capabilities (DVI playback) 480i/480p/576i/576p/720p/1080i/1080p (Support HDCP)
Display Mode
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
Pixel Clock
(MHz)
Sync Polarity
(Horizontal/Vertical)
720 x 400 31.47 70.0 28.3 -/+
640 x 480 31.47 60.0 25.1 -/-
640 x 480 37.5 75.0 31.5 -/-
800 x 600 37.88 60.0 40.0 +/+
800 x 600 46.88 75.0 49.5 +/+
1024 x 768 48.36 60.0 65.0 -/-
1024 x 768 60.02 75.0 78.7 +/+
1152 x 864 67.5 75.0 108.0 +/+
1280 x 1024 64.0 60.0 108.0 +/+
1280 x 1024 80.0 75.0 135.0 +/+
1920 x 1080 67.5 60.0 148.5 +/+
Model G2410H
Video input signals
Analog RGB, 0.7 Volts +/-5%, positive polarity at 75 ohm input impedance
Digital DVI-D TMDS, 600 mV for each differential line, positive polarity at 50
ohm input impedance
Synchronization input signals
Separate horizontal and vertical synchronizations, polarity-free TTL level, SOG
(Composite SYNC on green)
AC input voltage/frequency/current 100 to 240 VAC/50 or 60 Hz + 3 Hz/2.0 A (Max.)
Inrush current
120 V: 40 A (Max.)
240 V: 80 A (Max.)
Model G2410H
Connector type 15-pin D-subminiature, blue connector; DVI-D, white connector
Signal cable type Digital: Detachable, DVI-D, Solid pins, shipped detached from the monitor
Analog: Detachable, D-Sub, 15 pins, shipped attached to the monitor
Dimensions (with stand)
Height (extended) 463.81 mm (18.26 inches)
Height (compressed) 363.81 mm (14.32 inches)
Width 570.75 mm (22.47 inches)
Depth 184.12 mm (7.25 inches)
Dimensions (without stand)
Height 338.35 mm (13.32 inches)
Width 570.75 mm (22.47 inches)
Depth 62.0 mm (2.44 inches)
Stand dimensions
Height (extended) 363.82 mm (14.32 inches)
Height (compressed) 323.52 mm (12.74 inches)
Width 279.92 mm (11.02 inches)
Depth 184.12 mm (7.25 inches)
Weight
Weight with packaging 17.47 lb (7.94 kg)
Weight with stand assembly and cables 13.33 lb (6.06 kg)
