Statement of Volatility – Dell Latitude E6540
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
The Dell Latitude E6540 contains both volatile and non-volatile (NV) components. Volatile components lose their data
immediately after power is removed from the component. Non-volatile (NV) components continue to retain their data even
after power is removed from the component. The following NV components are present on the Dell Latitude E6540
system board.
Table 1. List of Non-Volatile Components on System Board
Description
Reference
Designator
Volatility Description
User
Accessible
for external
data
Remedial Action (Action
necessary to prevent loss of
data)
Embedded
Flash in
embedded
controller
MEC5075
U51 288 KB of embedded Flash
memory for keyboard
controller BIOS code, asset tag
and BIOS passwords
No N/A
Panel
EEDID
EEPROM
Part of panel
assembly Non Volatile memory, 512
bytes. No Part of panel assembly
System
BIOS
U53
Non Volatile memory, 32 Mbit
(4 MB), System BIOS and
Video BIOS for basic boot
operation, PSA (on board
diagnostics), PXE diagnostics. No N/A
Video
BIOS
Embedded in
system BIOS
Non Volatile memory, 512
kbit (64 KB), Graphics system
BIOS.
No
N/A
System
Memory –
DDR3L
memory
Two
SODIMM
connectors:
JDIMM1,2
Volatile memory in OFF state
NOTE: See state definitions later
in text.
One to two modules must be
populated. System memory
size will depend on SODIMM
modules and must be between
2 GB and 8 GB.
Yes Power off system
System
memory
SPD
EEPROM On System
memory
SODIMM(s)
– 1-2 present Non Volatile memory 512
Bytes.
Stores memory manufacturer
data and timing information
for correct operation of system
memory. No N/A
