Item
Component
Function
1
16 Gbps FC IN port (4)
Provides host-to-controller FC connection.
2
Seven segment display
sequence
Displays status or error codes for the storage array.
3
Controller power LED
Lights green when controller power is on.
Turns off when controller is not powered.
4
Controller fault LED
Lights amber when controller fault is detected.
Turns off when controller is operating normally
5
System identification LED
Blinks blue when system identification switch push-
button on enclosure front panel is pressed.
6
Cache active or cache offload
LED
Lights green when on-board controller memory
contains data.
If AC power fails, this LED changes to indicate Cache
Offload status. If the password reset function has
successfully changed the password, this LED flashes
on and off briefly.
7
Battery fault
Lights amber when battery backup unit or battery has
failed.
Turns off when battery backup unit is operating
normally
8
Management port
Provides a 100/1000 Mbps Ethernet connection for
out-of-band management of the enclosure.
9
Ethernet port (reserved)
Reserved port.
10
SAS IN port (2)
Provides host-to-controller SAS connection.
11
USB port
Does not provide any functionality.
12
Mini USB port
Reserved port.
13
Password reset switch
Activating this switch resets the password.
14
SAS OUT port (2)
Provides SAS connection for cabling to a downchain
expansion enclosure.
Host Channel LED Link Rate Indications
Below each FC port is a pair of LED indicators. The status of any FC port can be determined by applying
the following table to the condition of each LED pair.
LED 1
LED 0
CommRate
Off
Off
Link down
Off
On
2 Gbps
On
Off
4 Gbps
On
On
8 Gbps
