Dell Latitude E6330 (Mid 2012) - Manual (Page 77)

Display
Latitude E6330 13.3"
Dimensions:
Latitude E6230
Height 300.90 mm (11.84 inches)
Width 180.00 mm (7.08 inches)
Diagonal 317.30 mm (12.49 inches)
Active area (X/Y) 276.61mm x 155.52 mm
Latitude E6330
Height 314.10 mm (12.36 inches)
Width 188.70 mm (7.42 inches)
Diagonal 336.60 mm (13.25 inches)
Active area (X/Y) 293.42 mm x 164.97 mm
Maximum resolution 1366 x 768 pixels at 263 K colors
Maximum Brightness 200 nits
Operating angle 0° (closed) to 135°
Refresh rate 60 Hz
Minimum Viewing angles:
Horizontal +/- 40°
Vertical +10°/-30°
Pixel pitch 0.2148 mm
Keyboard
Number of keys United States: 86 keys, United Kingdom: 87 keys, Brazil: 87 keys,
and Japan: 90 keys
Layout QWERTY/AZERTY/Kanji
Touchpad
Active Area:
X-axis 80.00 mm
Y-axis 40.70 mm
Battery
Type
• 3-cell (32 WHr) Lithium-ion battery with ExpressCharge
• 6-cell (65 WHr) Lithium-ion battery with ExpressCharge
77
