Specifications – Dell Precision T3500 (Early 2009) User Manual
Page 10
Specifications
Dell Precision™ T3500 Service Manual
NOTE:
Offerings may vary by region. For more information regarding the configuration of
your Tablet-PC, click Start
(or Start in Windows XP)®
Help and Support, and then
select the option to view information about your Tablet-PC.
Processor
Processor types
Intel® Xeon® Processor 3500 series
Intel Xeon Processor 5500 series
System Information
System chipset
Intel X58+ ICH10
Data bus width
64 bits
Memory
Memory module connectors
Six
Memory module capacities
1 GB, 2 GB, or 4 GB
Memory type
DDR3 1066 MHz & 1333 MHz (Both ECC and Non-ECC)
Minimum memory
1 GB
Maximum memory
24 GB
Video
Video type:
Discrete
Two PCI Express 2.0 x16 slots
Note: Support for discrete full length full height
graphics option through PCIe x16 graphics card slot
Audio
Audio type
ADI1984A integrated audio
Expansion Bus
Bus type
PCI 2.3
PCI Express 2.0 (PCIe-x16)
PCI Express 1.1 (PCIe-x1)
SATA 1.0 and 2.0
USB 2.0
eSATA
Bus speed
133 MB/s (PCI)
x1-slot bidirectional speed - 500 MB/s (PCI Express)
x16-slot bidirectional speed - 8 GB/s (PCI Express)
1.5 Gbps and 3.0 Gbps (SATA)
480-Mbps high speed, 12-Mbps full speed, 1.2-Mbps
Low speed (USB)
PCI Connectors
connectors
Two
connector size
124 pins
connector data width (maximum)
32 bits
PCI Express x8
connector
Two
connector size
98 pins
PCI Express x16
connector
Two
connector size
164 pins
Drives
Externally accessible
One 3.5-inch drive bay (FlexBay), Two 5.25-inch drive
bays
Internally accessible
Two 3.5-inch SATA drive bays
