Dell Dimension 2010 User Manual

Page 62

Basic Specifications

External Connectors

USB

two front-panel, and

four back-panel USB

2.0-compliant connectors

NOTE: The USB connectors can

support devices with power rating up

to 10W @ 5V.

Network adapter RJ45 connector
Audio

front panel - microphone

and headphone

connectors
back panel - three

connectors for 5.1 support

Power

DC Power Supply
Wattage

300 W, 180 W

Maximum heat dissipation:
300 W

1621 Btu/h

180 W

944 Btu/h

NOTE: Heat dissipation is calculated by

using the power supply wattage rating.

Voltage:
300 W

115/230 VAC. 50/60 Hz,

7.0 A/4.0 A

180 W

220 VAC. 50/60 Hz, 4.0 A or
115/230 VAC. 50/60 Hz,

6.0 A/3.0 A

NOTE: For information on voltage

settings, see the safety information

on page 64.
