Using Your Studio XPS Desktop
1
USB 2.0 connectors (2) — Connect
to USB devices that are connected
occasionally such as memory keys, digital
cameras, and MP3 players.
2 Service Tag and Express Service Code —
Used to identify your computer when you
access the Dell Support website or call
technical support.
3
Microphone or line-in connector —
Connects to a microphone for voice or to
an audio cable for audio input.
4
Headphone connector — Connects
to headphones.
NOTE: To connect to a powered speaker or
sound system, use the audio out or S/PDIF
connector on the back of your computer.
5 Accessory tray — Used to place devices
or secure cables to avoid clutter.
6
Power button and light — Turns the
computer on or off when pressed. The light
in the center of this button indicates the
power state:
Off — The computer is either in
•
hibernate mode, turned off or is not
receiving power.
Solid white — The computer is on.
•
Solid amber — The computer is in
•
sleep state or there may be a problem
with either the system board or the
power supply.
Blinking amber — There may be a
•
problem with either the system board
or the power supply.
NOTE: For information on power problems,
