Dell M210X Projector - Manual (Page 51)

Dimensions (W x H x D) 8.07 x 2.99 x 6.10 inches (205 x 75.9 x 155 mm)
2.99"(75.9mm)
8.07"(205mm)
6.10"(155mm)
Environmental Operating temperature: 5ºC - 35ºC (41ºF- 95ºF)
Humidity: 80% maximum
Storage temperature: 0ºC to 60ºC (32ºF to 140ºF)
Humidity: 90% maximum
Shipping temperature: -20ºC to 60ºC
(-4ºF to 140ºF)
Humidity: 90% maximum
I/O Connectors Power: One AC power socket (3-pin - C14 inlet)
VGA input: One 15-pin D-sub connector (Blue), for
analog RGB/Component input signals.
S-Video input: One standard 4-pin min-DIN
S-Video connector for Y/C signal.
Composite video input: One Yellow RCA jack for
CVBS signal.
HDMI input: One HDMI connector for supporting
HDMI 1.3. HDCP compliant.
Analog Audio input: One 3.5 mm stereo mini phone
jack (Blue).
Variable audio output: One 3.5 mm stereo mini
phone jack (Green).
USB port: One USB slave for remote support.
Lamp OSRAM 165 W user-replaceable lamp (up to 5000
hours in eco mode)
Specifications 50
