Removing the Optical Drive | 65
3 Lift the optical-drive assembly off the computer base.
4 Remove the screws that secure the optical-drive bracket to the optical drive.
5 Remove the optical-drive bracket from the optical drive.
6 Remove the interposer from the optical drive.
1 screws (5) 2 optical-drive bracket
1 interposer
1
2
1
