Intel AMT in DHCP Mode Settings Example
The table below shows a basic field settings example for the Intel AMT Configuration menu page to configure the computer in DHCP mode.
Save and exit MEBx and then boot the computer to the Microsoft® Windows® operating system.
Intel AMT in Static Mode Settings Example
The table below shows a basic field settings example for the Intel AMT Configuration menu page to configure the computer in static mode. The computer
requires two MAC addresses (GBE MAC address and Manageability MAC Address) to operate in static mode. If there is no Manageability MAC address, Intel
AMT cannot be set in static mode.
Intel AMT Configurations Example in DHCP Mode
Intel AMT Configuration Parameters Values
Intel AMT Configuration Select and press .
Host Name
Example: IntelAMT
This is the same as the operating system machine name.
TCP/IP
Set the parameters as follows:
l Enable Network interface
l Enable DHCP Mode
l Set a domain name (e.g., amt.intel.com)
Provision Model
l Intel AMT 3.0 Mode
l Small Business
SOL/IDE-R
l Enable SOL
l Enable IDE-R
Remote FW Update Enabled
Intel AMT Configurations Example in Static Mode
Intel AMT Configuration Parameters Values
Intel AMT Configuration Select and press
Host Name Example: IntelAMT
TCP/IP
Set the parameters as follows:
l Enable Network interface
l Disable DHCP Mode
l Set an IP address (e.g., 192.168.0.15)
l Set a subnet mask (e.g., 255.255.255.0)
l The default gateway address is optional
l The preferred DNS address is optional
l The Alternate DNS address is optional
l Set the domain name (for example., amt.intel.com)
Provision Model
l Intel AMT 3.0 Mode
l Small Business
SOL/IDE-R
l Enable SOL
l Enable IDE-R
