Dell XPS 13 (9343, Early 2015) - Manual (Page 3)

1 Power‑adapter port
Connect a power adapter to provide power to your
computer and charge the battery.
2 Mini DisplayPort
Connect an external display or a projector.
3 USB 3.0 port
Connect peripherals such as storage devices, printers,
and so on. Provides data transfer speeds up to 5 Gbps.
4 Headset port
Connect a headphone, a microphone, or a headphone
and microphone combo (headset).
5 Battery‑charge status button
Press to check the charge remaining in the battery.
6 Battery‑charge status lights (5)
Turn on when the battery‑charge status button is
pressed. Each light indicates approximately 20% charge.
2 3 4 5 1 6
