Side view, Bottom view, Specifications – Dell E157FPT Monitor User Manual
Page 4
1.
Video connector
2.
Audio connector
3.
Power status LED indicator
4.
Touch status LED indicator
5.
Serial connector
6.
USB connector
7.
AC power
Side View
To adjust monitor angle:
1.
Loosen tilt-adjust knob.
2.
Position monitor as desired (range is from 30
o
to 90
o
).
3.
Tighten tilt-adjust knob. Do not over tighten.
Bottom view
Specifications
The following tables provide information about your touch screen monitor.
