1
Transmission EP-17488
Ref. No. Part No.
Description
Qty.
1
TC-772147
Transaxle Cover
1
2
TC-780086A Needle Bearing (1/2” long)
2
3
TC-770128A Transaxle Case
1
4
TC-776395
Countershaft
1
5
TC-776409
Output Shaft
1
6
TC-778364
Spur Gear (38T-PM/SER)
1
6A
TC-778369
Spur Gear (15T-PM/SER)
1
7
TC-778330
Spur Gear (11T-PM/SER)
1
8
TC-792180A Shift Key Set (Qty. 2)
2
9
TC-784352
Shift Collar
1
10
TC-784378
Shift Rod & Fork Assembly
1
11
TC-778334
Bevel Gear (30T-PM)
1
12
TC-778309
Input Bevel Pinion (13T-PM)
1
13
TC-778368
Bevel Gear 13T (Incl. ref. 13 & 14)
Complete Set of 4-gears
1
14
TC-778368
Bevel Gear 13T (Incl. ref. 13 & 14)
Complete Set of 4-gears
1
15
TC-778370
Ring Gear (43T)
1
17
TC-786188
Drive Pin
1
18
TC-786102
Spacer (1.130” x .695”)
1
20
TC-792077A Ball (Stainless Steel 5/16” dia.)
1
21
TC-792211
Screw, 3/8-16 x 3/8”
1
22
TC-792079
Spring
1
25
TC-792073A Screw, 1/4-20 x 1-1/4”
17
25A
TC-792177
Screw, 1/4-20 x 1-3/8”
2
26
TC-792125
Retaining Ring-package of 2
4
27
TC-792035
Retaining Ring
1
28
TC-788040
Retaining Ring
1
29
TC-780072
Washer .627” ID .031”
5
29A
TC-780160
Thrust Washer (.563” ID x .031”)
1
29B
TC-780051
Thrust Washer (.762” ID X .031”)
3
30
TC-780108
Shift Washer (Cupped)
3
31
TC-780001
Washer .750” ID .56”
2
31A
TC-780195
Washer .750” ID .062
2
32
TC-788083
Oil Seal 5/8”
1
32A
TC-792001
O Ring (.823” OD)
1
34
TC-780194
Bushing (.563”)
2
35
TC-780193
Flanged Bushing (.625” ID)
2
35A
TC-780197
Flanged Bushing (.751” ID)
2
36
TC-790075
Brake Disk
1
37
TC-790007
Brake Pad Plate
1
38
TC-799021A Brake Pad (pkg. of 2)
2
39
TC-786026
Dowel Pin .3125” x .750”
2
Ref. No. Part No.
Description
Qty.
40
TC-792076A Washer .312” ID .059”
1
41
TC-790104
Brake Lever
1
42
TC-792177
Screw 1/4-20 x 1-3/8”
1
43
TC-792075
Lock Nut 5/16-24
1
44
TC-790025
Brake Pad Holder
1
46
TC-786086
Bracket
1
47
TC-775146
Axle (10.719” long) (Incl. 26)
1
48
TC-775147
Axle (15.312” long) (Incl. 26)
1
49
TC-778338
Spur Gear (27T-PM/IC)
1
50
TC-778342
Spur Gear (22T-PM/IC)
1
51
TC-778313
Spur Gear (19T-PM/IC)
1
52
TC-778350
Spur Gear (16T-PM/IC)
1
56
TC-778337
Spur Gear (13T-PM/SER)
1
57
TC-778341
Spur Gear (18T-PM/SER)
1
58
TC-778351
Spur Gear (21T-PM/SER)
1
59
TC-778349
Spur Gear (24T-PM/SER)
1
63
TC-786071
Countershaft Spacer 1-1/8” x 3/8’’
2
64
TC-786072
Brake Shaft Spacer 1-3/8” x 3/8’’
2
65
TC-780189
Washer .563” ID .062
1
66
TC-776472
Input Shaft
1
67
TC-776396
Brake Shaft
1
69
TC-792170
Retaining Ring (.75” x .042”)
1
70
TC-786187
Spacer (.890”)
1
71B
TC-788092
O-Ring
1
76
TC-780090 Flat Washer (1.128” ID x .058”)
1
77
TC-788078A Retaining Ring (1.125” x .050”)
1
79
TC-792144
Spring
1
82
TC-778333
Bevel (30T) & Spur Gear
1
83
TC-778338
Spur Gear (27T-PM/IC)
1
85
TC-792154
Oil Fill Plug
1
87
TC-788089A Oil Seal 9/16” ID
1
157
TC-788088A Oil Seal 3/4” ID
2
