Cub Cadet Time Saver - Manual (Page 10)

10
Briggs & Stratton 10.5 H.P. Engine 215707-0507-E1
Ref. No. Part No. Description
1 BS-699045 Cylinder Assembly
2 BS-399265 Kit-Bushing/Seal (Magneto Side)
3 BS-391086s • Seal-Oil (Magneto Side)
4 BS-697106 Sump-Engine
5 BS-792964 Head-Cylinder
7 BS-273280s •+ Gasket-Cylinder Head
9 BS-697109 • Gasket-Breather
10 BS-697157 Screw (Breather Assembly)
11 BS-697113 Tube-Breather
12 BS-697110 • Gasket-Crankcase
13 BS-690360 Screw (Cylinder Head)
15 BS-691680 Plug-Oil Drain
16 BS-698382 Crankshaft
20 BS-791892 • Seal-Oil (PTO Side)
22 BS-692125 Screw (Crankcase Cover)
23 BS-693557 Flywheel
24 BS-222698s Key-Flywheel
25 BS-698767 Piston Assembly (Standard)
BS-698769 Piston Assembly (.020” Oversize)
26 BS-698375 Ring Set (Standard)
BS-698377 Ring Set (.020” Oversize)
27 BS-698469 Lock-Piston Pin
28 BS-697099 Pin-Piston (Standard)
29 BS-791633 Rod-Connecting (Standard)
32 BS-791118 Screw (Connecting Rod)
33 BS-791934 Valve-Exhaust
34 BS-791935 Valve-Intake
35 BS-691279 Spring-Valve (Intake)
36 BS-691279 Spring-Valve (Exhaust)
37 BS-697352 Guard-Flywheel
37A BS-697626 Guard-Flywheel
42 BS-499586 Keeper-Valve
43 BS-691968 Slinger-Governor/Oil
45 BS-690564 Tappet-Valve
46 BS-793583 Camshaft
48 BS-697740 Short Block
50 BS-697361 Manifold-Intake
51 BS-692137 • ؇+ Gasket-Intake
53 BS-690227 Stud (Carburetor)
54 BS-691148 Screw (Intake Manifold)
73 BS-697133 Screen-Rotating
74 BS-697897 Screw (Rotating Screen)
78 BS-691003 Screw (Flywheel Guard)
78A BS-690364 Screw (Flywheel Guard)
81 BS-691178 Lock-Muffler Screw
94 BS-695425 Kit-Idle Mixture
95 BS-690718 Ø Screw (Throttle Valve)
98 BS-695408 Kit-Idle Speed
104 BS-694918 Ø Pin-Float Hinge
105 BS-696136 Valve-Float Needle
108 BS-698773 Valve-Choke
117 BS-699897 Jet-Main (Standard)
118 BS-699898 Jet-Main (High Altitude)
121 BS-698787 Kit-Carburetor Overhaul
125 BS-791178 Carburetor
127 BS-690727 Plug-Welch
130 BS-698774 Valve-Throttle
131 BS-698776 Kit-Throttle Shaft
133 BS-694914 Float-Carburetor
Ref. No. Part No. Description
135 BS-698780 Tube-Fuel Transfer
137 BS-698781 ؇ Gasket-Float Bowl
141 BS-698778 Kit-Choke Shaft
146 BS-691639 Key-Timing
187 BS-791805 Line-Fuel (Cut to Required Length)
188 BS-691693 Screw (Control Bracket)
192 BS-691986 Adjuster-Rocker Arm
202 BS-691841 Link-Mechanical Governor
209 BS-792602 Spring-Governor
216 BS-691840 Link-Choke
222 BS-694042 Bracket-Control
227 BS-691374 Control Lever-Governor
232 BS-691842 Spring-Governor Link
238 BS-691843 Cap-Valve
240 BS-394358s Filter-Fuel
265 BS-691024 Clamp-Casing
267 BS-690804 Screw (Casing Clamp)
300 BS-697048 Muffler
304 BS-698473 Housing-Blower
305 BS-697102 Screw (Blower Housing)
305A BS-793376 Screw (Blower Housing)
306 BS-697359 Shield-Cylinder
307 BS-691003 Screw (Cylinder Shield)
309 BS-693551 Motor-Starter
310 BS-690323 Screw (Starter Motor)
311 BS-497608 Brush Set
333 BS-492341 Armature-Magneto
334 BS-691061 Screw (Armature Magneto)
337 BS-491055s Spark Plug
356 BS-398808 Wire-Stop
358 BS-697151 Gasket Set-Engine
359 BS-691077 Nut (Ground Terminal)
363 BS-19203 Flywheel Puller
373 BS-691612 Nut (Ground Terminal)
383 BS-89838s Wrench-Spark Plug
404 BS-691691 Washer (Governor Crank)
431 BS-697122 Elbow-Intake
445 BS-698413 Filter-Air Cleaner Cartridge
474 BS-696578 Alternator
505 BS-691251 Nut (Governor Control Lever)
507 BS-691972 Insulator
510 BS-693699 Drive-Starter
513 BS-692024 Clutch-Drive
520 BS-691084 Terminal-Ground
521 BS-690581 Shield-Cable
523 BS-699908 Dipstick
524 BS-691032 • Seal-Dipstick Tube
525 BS-697184 Tube-Dipstick
544
Starter-Armature (For Service order 693551
Starter Motor)
552 BS-697144 Bushing-Governor Lever
562 BS-691119 Bolt (Governor Control Lever)
579 BS-691029 Nut (Starter Cable)
584 BS-697112 Cover-Breather Passage
601 BS-791850 Clamp-Hose
613 BS-691416 Screw (Muffler)
613A BS-691678 Screw (Muffler)
614 BS-691620 Pin-Cotter
616 BS-692012 Crank-Governor
