Cub Cadet 365 - Manual (Page 33)

33
Model 364
REF.
NO.
PART
NO. DESCRIPTION
1. 751-3141 Oil Drain Extension Hose
2. 751-3142 Oil Drain Cap
3. 751-3140 Oil Drain
4. 710-3009 Tap Screw #10-24 x .75
5. 746-3070 Throttle Cable
6. 746-3069 Choke Cable
7. 712-0161 Hex Lock Nut #10 - 24
8. 710-0751 Hex Cap Screw 1/4-20 x .620
9. 736-3006 Lock Washer 1/4 x 3/4
10. 736-0270 Bell Washer .265 x .75
11. 726-0205 Hose Clamp
12. 751-0535 Fuel Line Hose
13. 725-3001 Solenoid Switch
14. 712-0291 Hex Lock Nut 1/4-20
15. 736-0119 Lock Washer 5/16
16. 712-3010 Hex Nut 5/16-18
17. 712-3071 Hex Nut #10-32
18. 712-0431 Flange Lock Nut 3/8-16
19. 703-2859 Muffler Bracket
20. 710-3178 Carriage Bolt 3/8-16 x .75
21. 710-0642 Hex Washer Screw 1/4-20 x .75
22. 721-0460 Gasket
23. 751-0650 Exhaust Pipe - RH
24. 710-1314 Cap Screw 5/16-18 x .625
25. 703-3004 Muffler Guard
26. 751-0616 Muffler
27. 710-0148 Hex Washer Screw #8-32 x .375
28. 751-0564 Muffler Deflector
29. 751-0651 Exhaust Pipe - LH
30. 747-3362 Rear Belt Retainer Rod
31. 736-0258 Flat Washer .385 x 1.0
32. 603-0317 Clutch Retainer Ass’y
33. 710-1237 Hex Washer Screw #10-32 x .625
34. 751B221535 Casing Clamp
35. 726-3008 Heat Shield Cable Clip
36. 712-0291 Hex Lock Nut 1/4-20
37. 710-1007 Hex Washer Screw 3/8-16 x 1.5
38. 710-1008 Hex Washer Screw 3/8-16 x 1.875
39. 736-3010 Flat Washer .407 x .812 x .135
40. 754-3100 V-Belt
41. 756-3060A Transmission Drive Pulley
42. 714-0128 Key 1/4 x 1.0
43. 725-0157 Cable Tie
44. 717-3467 Electric Clutch
45. 750-3106 Spacer Clutch
46. 736-0171 Lock Washer
47. 710-3157 Hex Cap Screw 7/16-20 x 3.25
629-3038A Engine Harness Assembly (Not Shown)
