Fan
Dell™ OptiPlex™ XE Service Manual— Desktop
Removing the Fan
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the front panel .
3. Remove the optical drive .
4. Remove the secondary hard drive .
5. Remove the primary hard drive .
6. Remove the heat-sink fan .
7. Disconnect the fan cable from the system board.
8. Release the fan cable from its routing guide on the chassis.
9. Remove the screws that secure the fan to the chassis.
10. Remove the fan from the computer.
Replacing the Fan
To replace the fan, perform the above steps in reverse order.
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe® Flash® Player from Adobe.com in order to view the illustrations below.
