Crestron SMK-6X Swivel Mount Kit for TPS-6X
Swivel Mount Kit for TPS-6X:
SMK-6X
Introduction
Features and Functions
• Designed for attachment to the TPS-6X-DS desktop docking station
• Swivel mount increases security by reducing chance of theft while
improving viewing convenience
• Base rotates 330 degrees
• Mounts on the desktop, in a lectern or on a conference table
• Accommodates surface thickness from 3/4 inch (1.91 cm) minimum to
1 3/8 inches (3.50 cm) maximum, using the hardware provided
• Cables route through center of assembly, keeping cables completely
hidden from work surface
• Customizable swivel range for added security and convenience
Specifications
Specifications for the SMK-6X are listed in the following table.
SMK-6X Specifications
SPECIFICATION DETAILS
Dimensions
Height 2.64 in (6.69 cm)
Width 6.09 in (15.45 cm)
Depth 5.80 in (14.74 cm)
Weight 0.96 lbs (0.44 kg)
Installation Guide – DOC. 6577A Swivel Mount Kit for TPS-6X: SMK-6X • 1
