Using Your Projector 17
Using the Control Panel
Screen
(Diagonal)
Max.
25.2"
(64.1cm)
75.7"
(192.3cm)
126.2"
(320.5cm)
176.7"
(448.7cm)
227.1"
(576.9cm)
302.8"
(769.2cm)
Min.
22.89"
(58.3cm)
68.8"
(174.8cm)
114.7"
(291.4cm)
160.6"
(407.9cm)
206.5"
(524.5cm)
275.3"
(699.3cm)
Screen
Size
Max.
(WxH)
20.2"X15.1" 60.6" X45.4" 101.0" X 75.7" 141.3" X106" 181.7" X 136.3" 242.3" X 181.7"
(51.3cm X
38.5cm)
(153.8cm X
115.4cm)
(256.4cm X
192.3cm)
(359.0cm X
269.2cm)
(461.5cm X
346.2cm)
(615.4cmX
461.5cm)
Min.
(WxH)
18.3" X 13.7" 55.1" X 41.3" 91.8" X 68.8" 128.5" X 96.4" 165.2" X 123.9" 220.3" X 165.2"
(46.5cm X
34.9cm)
(139.9cm X
104.9cm)
(233.1cm X
174.8cm)
(326.3cm X
244.8cm)
(419.6cm X
314.7cm)
(559.4cm X
419.6cm)
Hd
Max.
2.27"
(5.8cm)
6.81"
(17.3cm)
11.36"
(28.8cm)
15.9"
(40.4cm)
20.44"
(51.9cm)
27.26"
(69.2cm)
Min.
2.06"
(5.2cm)
6.19"
(15.7cm)
10.32"
(26.2cm)
14.45"
(36.7cm)
18.58"
(47.2cm)
24.78"
(62.9cm)
Distance 3.3' (1.0m) 9.8' (3.0m) 16.4' (5.0m) 23.0' (7.0m) 29.5' (9.0m) 39.4' (12.0m)
* This graph is for user reference only.
1 LAMP warning light If the LAMP light is solid amber, replace the
lamp. If the LAMP light is blinking amber, the
projector automatically shuts down indicating a
system failure. If this problem persists, contact
Dell.
1 3
5
2
7
9
4
8
6
