Pull the hard-drive blank out until it is free of the hard-drive slot.

Figure 13. Removing and Installing a 2.5 Inch Hard-Drive Blank (Back)

1. hard-drive blank (back)

Installing A 2.5 Inch Hard-Drive Blank (Back)

Insert the hard-drive blank into the hard-drive slot until it clicks into place.

Removing A 3.5 Inch Hard-Drive Blank

CAUTION: To maintain proper system cooling, all empty hard-drive slots must have drive blanks installed.

1.

If installed, remove the front bezel.

2.

Grasp the front of the hard-drive blank, press the release button and slide the blank out until it is free of the hard-

drive slot.

Figure 14. Removing and Installing a 3.5 Inch Hard-Drive Blank

1. hard-drive blank
2. release button

45
