D e s k t o p S e t u p — W i t h o u t E x p a n s i o n C a r d s
D e s k t o p S e t u p — W i t h E x p a n s i o n C a r d s
NOTE: If your system has two video connectors, the integrated video connector is disabled and
has a protective cap on it. Use the expansion card connector as shown in the illustration. For
more information on setting up monitors with your specific graphics card, see "Monitor
Connections" on page 16.
A
B
C
D
monitor
keyboard
mouse
speakers
network
USB
A B
C
D
LINE OUT
monitor
flat-panel
monitor
speakers
network
