Removing the display bezel – Dell Precision M4300 (Mid 2007) User Manual
Page 15
10.
From the back of the computer, remove the two M2.5 x 5-mm screws.
11.
Turn the computer top-side up and open the display.
12.
Lift the display assembly out of the computer base.
Removing the Display Bezel
1.
Follow the procedures in
Before You Begin
.
2.
Remove the display assembly (see
).
3.
Remove the six rubber display bumpers and two mylar screw covers from around the display bezel.
4.
Remove the eight M2.5 x 4.2 x 5-mm shoulder screws from around the display bezel.
1
M2.5 x 5-mm screws labeled "D" (2)
1
M2.5 x 5-mm screws (2)
CAUTION:
Before performing the following procedures, follow the safety instructions in the Product Information Guide.
NOTICE:
To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching a connector on the back panel of
the computer.
1
screw covers/display bumpers (8)
2
display bezel
1
screws (8)
2
display bezel
3
top cover
NOTICE:
Carefully separate the bezel from the top cover to avoid damage to the bezel.
