Battery

Type

6‑cell “smart” lithium‑ion (45 WHr)

Dimensions:

Height

5.16 mm (0.20 inch)

Width

113.16 mm (4.46 inches)

Depth

287.00 mm (11.30 inches)

Weight

0.28 kg (0.62 lb)

Voltage

7.40 VDC

Operating time

Battery operating time varies depending on
operating conditions and can significantly reduce
under certain power‑intensive conditions

Life span (approximate)

300 discharge/charge cycles

Temperature range:

Operating

0 °C to 35 °C (32 °F to 95 °F)

Storage

–40 °C to 65 °C (–40 °F to 149 °F)

Coin‑cell battery

CR‑2032

Power Adapter

Type

45 W

Input voltage

100 VAC–240 VAC

Input current (maximum)

1.30 A

Input frequency

50 Hz–60 Hz

Output current

2.31 A

Rated output voltage

19.50 VDC

Temperature range:

Operating

0 °C to 40 °C (32 °F to 104 °F)

Storage

–40 °C to 70 °C (–40 °F to 158 °F)
