5 Specifications
Light Valve 0.45" WXGA S450 DMD, DarkChip3™
Brightness 450 ANSI Lumens (Max.)
Contrast Ratio 10000:1 Typical (Full On/Full Off)
Uniformity 80% Typical (Japan Standard - JBMA)
Number of Pixels 1280 x 800 (WXGA)
Aspect Ratio 16:10
Internal Flash 1 GB Memory (Max.)
Displayable Color 1.07 billion colors
Projection Lens F-Stop: F/2.0
f=14.95 mm
Fixed Lens
Throw ratio =1.5 wide and tele
Offset ratio: 100%
Projection Screen Size 30~80 inches (diagonal)
Projection Distance 3.18~8.48 ft (97~258 cm)
Video Compatibility HDMI input: 1080p, 720p, 576i/p, 480i/p
Power Supply Universal AC 100-240 V 50-60 Hz with 65 W
power adapter
Power Consumption Normal mode: 52 W ± 10% @ 110 Vac
Eco mode: 42 W ± 10% @ 110 Vac
Power saving mode: < 0.5 W (Fan speed at
minimum)
Standby mode: < 0.5 W
Audio 1 speaker x 1 watt RMS
Noise Level Normal mode: 36 dB(A) Typical
Eco mode: 32 dB(A) Typical
Weight 0.8 lbs ± 0.05 lbs (0.36 kg ± 0.02 kg)
Specifications 54
