Char-Broil 7201560 User Manual
Page 11
18
17
NOTE: Smoker chamber door not pictured for clarity.
If you wish to grill in the smoker chamber, place two of the three
wire fire grates into bottom of smoker chamber. Place two large
porcelain cooking grates into chamber, resting them on the grate
support screws.
Large Porcelain
Cooking Grate (2)
Wire Fire Grate (2)
Grate Support
Screws
Firebox Fire Grate Installation for Smoking or Grilling:
NOTE: Firebox side door not pictured for clarity.
Place remaining wire fire grate into bottom of firebox through firebox door.
Wire Fire Grate (1)
