CFM UVHK31MP - Manual (Page 17)

17 20008056
T100
log notch
on valve cover
10/15/03 djt
Valve
Cover
T100
Fig. 15 Position log so notch fits securely and rests on valve
cover.
T101
secure front log
10/15/03 djt
Front Log
End Bar Should
Fit in V-Shaped
Depression in the
Bark
T101
Fig. 16 Front end of frontlog should touch grate bar.
T124
Side view
logset
10/28/03 djt
Log Spacer
Bracket Control
Cover
Rear Log Bracket
T124
All Other
Logsets
Charred Oak
Only
Fig. 17 When using Charred Oak logsets, the rear log spacer
bracket must be cut for the rear log to sit properly.
