Workgroup Remote Access Switch 99
A PPLE T ALK R OUTING N ETWORK
Configure the CyberSWITCH
C ONFIGURING A PPLE T ALK P ORT I NFORMATION
For this example, we need to configure both a LAN and a WAN UnNumbered AppleTalk port. The
LAN AppleTalk port represents SITE1’s connection to its LAN AppleTalk network, allowing SITE1
to exchange packets with the two MACs on the LAN. The WAN UnNumbered port creates a logical
AppleTalk network over WAN that uses unnumbered point-to-point links, allowing SITE1 to
exchange packets with SITE2.
We will begin with configuring the LAN AppleTalk port. Select AppleTalk Ports from the AppleTalk
Routing Menu. Then, press 1 to add a port. You will then be prompted for port information as
shown below:
Use the following information to clarify each of the port information entries:
• port type:
Press 1 to select the LAN port type (this indicates that the system is physically connected to an
Ethernet LAN segment.
• port name:
The port name is a 1 to 16 character device-defined string that will identify the LAN port to the
system administrator. Enter lanport1 for the port name.
• port number:
Enter 1 for the port number of the AppleTalk LAN port. This is the port number on the Ethernet
resource to which the physical LAN is connected.
• AppleTalk network type:
Choices are: extended or nonextended network. The extended network allows addressing of
more than 254 nodes and supports multiple zones, whereas the nonextended network allows up
to 254 nodes and supports only one zone.This network requires a range of network numbers and
multiple zones. Select the extended network type.
AppleTalk Port Type:
1) LAN
2) WAN
3) WAN (UnNumbered)
4) WAN (Mac Dial In)
Enter a port type from the above menu or to cancel? 1
Enter the port name or to cancel ? lanport1
Enter the LAN port number or to cancel? 1
AppleTalk Network Type:
1) Extended Network
2) NonExtended Network
Enter a network type from the above menu or to cancel? 1
Enter the AppleTalk network range. Use 0-0 to place the port into
discovery mode or to cancel? 10-13
Enter the suggested AppleTalk address [default = None] ?
Enter the default zone name or to cancel ? SITE1.Engineering
