EXAMPLE NETWORKS
46 CyberSWITCH
Corporate Office
ISDN
Host
File Server
128.1.1.1
RLAN Interface
198.12.10.1
BRIs
BRI
BRI
HDLC Bridge
HDLC Bridge
Host
Host
"Carmel"
"Monterey"
IP (Sub-) Network Number
131.12.10.0
Remote Satellite
Offices
POWER SERVICE TX RX 10BASE - T LAN B-CHANNELS E1 ONLY
B2 B4 B6 B8 B26 B28 B22 B24 B18 B20 B14 B16 B10 B12 B30 L1
B1 B3 B5 B7 B25 B27 B21 B23 B17 B19 B13 B15 B9 B11 B29 B31 E1 D T1 D
CSX1200
198.12.10.2
198.12.10.3
"Corp"
N ETWORK T OPOLOGY
