Workgroup Remote Access Switch 29
IP R OUTING N ETWORK
Initial Installation Steps
N ETWORK T OPOLOGY
File Server
BRI BRI
BRI BRI
PC
PRI
128.1.1.1
192.1.1.2
Fred Bear
128.1.1.3
Todd Jones
192.1.1.3
Ralph Moose
128.1.1.2
Jill Smith
ISDN
LAN 131.1.0.0
Router 1 131.1.1.16
128.1.1.16
WAN Direct Host Interface and
WAN Interface 192.1.1.1
Host
Host Host
Host
SITE:
San Fran
POWER SERVICE TX RX 10BASE - T LAN B-CHANNELS E1 ONLY
B2 B4 B6 B8 B26 B28 B22 B24 B18 B20 B14 B16 B10 B12 B30 L1
B1 B3 B5 B7 B25 B27 B21 B23 B17 B19 B13 B15 B9 B11 B29 B31
E1 D T1 D
