Workgroup Remote Access Switch 13
S IMPLE R EMOTE B RIDGING N ETWORK
Bridging and Routing Information
The next item that you need to configure is the Data Link for the line. Depending on the switch type,
there may be more than one Data Link per line. In our example, we use one Data Link with
Automatic TEI Negotiation:
After entering the above information, press to display the line menu. Because there are
four lines in this example, the steps for adding a line should be repeated for lines 2, 3, and 4. After
all lines have been added, press twice to return to the Main Menu.
C ONFIGURING THE O PTIONS
The default configuration for the CyberSWITCH is bridging disabled and IP routing enabled. For
reasons we provide below, we want both bridging and IP routing enabled. Under the Option Menu,
select the bridging option and follow the instructions to enable bridging.
This network is a bridged network, but we are going to configure an IP option (the IP host operating
mode) so that we may use an IP application (such as Telnet, TFTP, or SNMP) to manage the
CyberSWITCH. Refer to the graphic below for clarification.
LINE TYPE = BR_ISDN
1) POINT_TO_POINT
2) POINT_MULTIPOINT
Select Option [default = POINT_TO_POINT] or press for previous menu: 1
Current DATA LINK Configuration for this line:
id TEI
-- ----
There are currently no Data Links configured for this line.
Enter (1) to Add or press for previous menu: 1
Automatic TEI Negotiation (Y or N) [default = Y]? Y
Current Data Link Configuration for this line:
id TEI
-- ----
1 AUTO
(1) Add, (2) Change, (3) Delete a DATA LINK or press for previous menu?
