Page 32
32
Dutchwest Sequoia
2001049
Sequoia Woodburning Stove
Model 2160
(continued)
Item Description
Part Number
15. Side, Left
7000996
16. Plate, Side Door Hinge
700G808
17. Door, Side
7001001
18. Front, Sequoia
7000998
19. Door, Front
7001002
20. Gasket, Fiberglass 3/8 - Low D, 6ND
1203589
21. Hinge, Front Door Upper
700G806
23. Latch, Door w/Set Screw
7000836
24. SS. Soc 5/16 - 18 x 5/16 Blk
1200563
25. Glass
7001011
26. Retainer. Glass
7001012
27. Trim, Glass - Brass
7001013
28. Bypass Gate
7000954
29. Adjuster, Bypass
7000950
34. Tab, Damper
1601488
35. Crank, Bypass Gate
7000951
36. Gasket, Fiberglass 3/16 4ND Blk
1203556
37. Ashdoor
7000820
38. Pin, Hinge - Ash Door
1201837
39. Hearth
7001100
40. Rod, Operating - Bypass Gate
7001131
41. Grate, Rocker
7001092
42. Cover,Shaker Grate
7000803
43. Seal, Grate
7001090
44. Grate, Fixed Section
7000802
Item Description
Part Number
45. Frame, Grate
7000999
46. Back, Grate
7000808
48. Top
7001000
49. Fan Plate, Brass
1406063
50. Flue Collar (6” Diameter)
1305050
Flue Collar (8” Diameter)
1304280
52. Leg - 6”
7000829
53. Handle Assy - Vert. Align Gold
5004271
55. Refractory
1602515
57. Dial Damper, Brass - LG
7000011
62. Grate Tool,Shaker
7000835
64. Ashpan
700G802
66. Blower (Optional)
0009973
70. Thermometer, Cat. Probe
0000948
72. Rear Heat Shield (Optional)
0001060
73. Andiron (Optional)
7001008
74. Inner Top Web*
7001110
75. Air Manifold
7001006
76. Nut, Hex Jam 3/8-16 TOPLK-Z
1203290
77. Damper Handle Stub w/Screw - Gold
5004267
78. Divider, Air
30001900
79. Plate, Fan
7000831
80. 5/8 I.D. Washer
1202561
81. Retaining Ring, E Style s/s
1203058
