12
Dutchwest Sequoia
2001049
Sequoia Clearance Chart
Stove Clearance
Stove Installed
Parallel to Wall
Unprotected Surfaces Protected Surfaces
Side Rear Corners Side Rear Corners
No stove
heat shields 1
Chimney Connector Clearance
Unprotected Vertical Surfaces Protected Vertical Surfaces
Clearance to Combustibles in Front of Stove
48” (1219mm)
36” (914mm) 19” (483mm)
14” (356mm) 8” (203mm)
All Installations
Stove Installed
Parallel to Wall
Stove
in
Corner
Stove
in
Corner
Stove, top exit with rear
heat shield, no connector
heat shields
(A) 32” (B) 42” (C) 36” (D) 16” (E) 26” (F) 20”
(813mm) (1067mm) (914mm) (406mm) (660mm) (508mm)
(M) 32” (N) 20” (O) 26” (P) 16” (Q) 14” (R) 12”
(813mm) (508mm) (660mm) (406mm) (356mm) (305mm)
(G) 32” (H) 42” (I) 36” (J) 16” (K) 26” (L) 20”
(813mm) (1067mm) (914mm) (406mm) (660mm) (508mm)
Stove, top exit with rear
heat shield, and heat
shields on connector 1,2,3
Stove, rear exit with rear
heat shield only
(S) 32” (T) 20” N/A (U) 16” (V) 14” N/A
(813mm) (508mm) (406mm) (356mm)
No chimney connector
heat shields
Chimney connector
heat shields installed
2
1 All installations venting straight up to a factory-built chimney require a 24” (610mm) diameter or square ceiling heat
shield. The ceiling heat shield should be 24 gauge sheet metal or equivalent mounted on 1” (25mm) noncombustible
spacers 1” (25mm) below ceiling.
2 Shielding for a top exit stove must include a shield insert to protect the area behind the flue collar.
3 Chimney connector heat shields must extend to within 1” (25mm) or less of the ceiling heat shield for installations
venting straight up to a factory-built chimney. Top exit installations using an elbow to vent to rear chimney connector
must be shielded over entire vertical length.
