N.I.C.E. P200
31
Attach the mounting bracket to the glass
1.
Place the windshield mounting bracket in
position with the suction cup touching the glass.
N.I.C.E. P200 mounted on the glass
Suction cup
Compression lever
Adjustment knob: (two
more on other side)
Windshield
mounting
bracket
Make sure the assembly does not obstruct the
driver’s view of the road from any angle, but still
has a direct path through the windshield to the
GPS satellite.
If you are not sure consult a
professional installer for help.
2.
Press the compression lever.
3.
Adjust the position of the N.I.C.E. P200 using
the adjustment knobs.
Connect the vehicle power cord
In a vehicle, the N.I.C.E. P200’s is powered by the
vehicle power cord connected from the DC IN
socket on the cradle to the car’s cigarette lighter.
Note
