E-10
1 An indicator appears next to the type of setting you are currently performing (TONE, RHYTHM, SONG BANK).
2 Tone number, rhythm number, song number, keyboard settings value
3 Rhythm, auto-accompaniment, Song Bank tune beats
4 Tone name, rhythm name, song name, mode name, keyboard settings name
5 Musical staff representation of notes and chords you play on the keyboard. A pedal indicator ( ) appears when the keyboard's pedal is
depressed. An octave indicator ( ) appears when you play notes in the range from C 6 to C7 to indicate that their actual notation is one
octave higher than that shown on display.
6 Uses a graphic keyboard to show notes and chords played on the keyboard or played during Song Bank tune playback
7 Auto-accompaniment, Song Bank, chord book chord names
8 Dots indicate fingerings during Song Bank playback. “L” and “R” indicate left-hand and right-hand parts.
9 Rhythm, auto-accompaniment, Song Bank tune tempo
10 Rhythm, auto-accompaniment, Song Bank tune tempo; volume setting
11 Song Bank controller indicators
❚ NOTE ❚
Display examples shown in this User’s Guide are intended for illustrative purposes only. The actual text and values that appear on the display may differ from
the examples shown in this User’s Guide.
Using the Display
• This is how the display appears while the
Song Bank is in use.
622A-E-012A
4
TONE
RHYTHM
SONG BANK
STATUS
TEMPO
MAIN VOLUME
1
2 5
10
11
3
7 8 9
6
