DMX-44 User Manual 8 Revised: 2006-01-13 21:30:19
O
PERATING
I
NSTRUCTIONS
Setup
S ET T I N G U P T H E SY ST EM
1) Place the DMX-44 on a leveled surface. Note! The DMX-44 can also be rack mounted,
occupying 3U spaces by removing the outer rubber edge guard.
2) Plug the AC to DC power supply to the system back panel and to the mains outlet.
3) Plug in your DMX cable(s) to your intelligent lighting as described in the fixtures respective
manual. For a quick Primer on DMX see the
“DMX Primer” section in the Appendix of this
manual.
F I XT U R E AD D R E S S I N G
The DMX-44 is programmed to control 16 channels of DMX per fixture, therefore the fixtures you wish
to control with the corresponding
“
SCANNER
” buttons on the unit, must be spaced
16 channels apart.
F IXTURE OR
S CANNER #
D EFAULT DMX S TARTING
A DDRESS
B INARY D IPSWITCH S ETTINGS
S WITCH TO THE
“
O N POSITION
”
1 1 1
2 17 1,5
3 33 1,6
4 49 1,5,6
5 65 1,7
6 81 1,5,7
7 97 1,6,7
8 113 1,5,6,7
9 129 1,8
10 145 1,5,8
11 161 1,6,8
12 177 1,5,6,8
Please refer to your individual fixture
’s manual for DMX addressing instructions. T
he table above
refers to a standard 9 dipswitch binary configurable device.
