Tank Gauge Assembly 3
First, secure temperature probe the clamp on the left side
panel show A.
Make the gauge wire go through the hole on the left side
shelf and insert to the tank gauge show B and C.
A
B
C
Gauge Wire
Gauge Wire
Temperature Probe
Clamp
