XLS Series Power Amplifiers
page 18 Operation Manual
Performance XLS 202 XLS 402 XLS 602
Damping Factor (8 ohm): 10 Hz to 400 Hz > 200 > 200 > 200
Crosstalk (below rated power,
at 1 kHz
at 20 kHz
–82 dB
–58 dB –82 dB
–58 dB –82 dB
–58 dB
DC Output Offset (Shorted input) ± 10 mV ± 10 mV ± 10 mV
Input Impedance (nominally balanced, nominally unbalanced) 20 kilohms, 10 kilohms 20 kilohms, 10 kilohms 20 kilohms, 10 kilohms
Load Impedance (Note: Safe with all types of loads)
Stereo
Bridge Mono
2-8 ohms
8 ohms
2-8 ohms
8 ohms
2-8 ohms
8 ohms
Voltage Gain (at maximum level setting) 31 dB 31 dB 31 dB
AC Line Voltage and Frequency Configurations Available (± 10%) 120 VAC/60 Hz and 230 VAC/50 Hz 120 VAC/60 Hz and 230 VAC/50 Hz 120 VAC/60 Hz and 230 VAC/50 Hzz
Construction XLS 202 XLS 402 XLS 602
Ventilation Flow-through ventilation from front to back Flow-through ventilation from front to back Flow-through ventilation from front to back
Cooling Internal heat sinks with forced-air cooling Internal heat sinks with forced-air cooling Internal heat sinks with forced-air cooling
Air Volume Requirements (per minute per unit) 80.15 ft 3 (2.27 m 3 ) 80.15 ft 3 (2.27 m 3 ) 80.15 ft 3 (2.27 m 3 )
Dimensions: Width, Height, Depth (behind mounting surface) EIA Standard19"W (EIA RS-310-B)
x 3.5” (8.9 cm) H x14" (35.6cm) D
EIA Standard19"W (EIA RS-310-B)
x 3.5” (8.9 cm) H x14" (35.6cm) D
EIA Standard19"W (EIA RS-310-B)
x 3.5” (8.9 cm) H x14" (35.6cm) D
Net Weight, Shipping Weight 21.0 lb (9.5 kg), 26.0 lb (11.8 kg) 25.3 lb (11.5 kg), 30.3 lb (13.8 kg) 27.2 lb (12.3 kg), 32.2 lb (14.6 kg)
6 Specifications
