PARTS LIST – Model No. 463268008
Key Qty Description
Part #
A
1
Bottom Shelf. . . . . . . . . . . . . . . . . . . . . 80013428
B
2
Locking Caster . . . . . . . . . . . . . . . . . . . 80000268
C
2
Fixed Caster . . . . . . . . . . . . . . . . . . . . . 80004093
D
1
Left Side Panel, Firebox . . . . . . . . . . . . 80008177
E
1
Right Side Panel, Firebox. . . . . . . . . . . 80008178
F
1
Lower Back Panel, Cart . . . . . . . . . . . . 80065508
G
1
Heat Shield, Tank, with Extension . . . . 80005603
H
1
Front Brace. . . . . . . . . . . . . . . . . . . . . . 80005602
I
1
Electronic Ignition Button . . . . . . . . . . . 80004343
J
1
Left Rail, Grease Tray . . . . . . . . . . . . . 80005604
K
1
Right Rail, Grease Tray . . . . . . . . . . . . 80005605
L
1
Firebox Bowl. . . . . . . . . . . . . . . . . . . . . 80013456
M
1
Left Side Upper Panel . . . . . . . . . . . . . 80005586
N
1
Right Side Upper Panel . . . . . . . . . . . . 80005585
O
1
Left Side Panel, Cart . . . . . . . . . . . . . . 80005598
P
1
Right Side Panel, Cart . . . . . . . . . . . . . 80005599
Q
1
Match Holder w/Chain . . . . . . . . . . . . . 80006654
R
1
Rear Upper Panel. . . . . . . . . . . . . . . . . 80005590
S
4
Burners w/Spider Guards . . . . . . . . . . . 80013421
T
1
Valve/Manifold/Regulator . . . . . . . . . . . 80008813
U
1
Control Panel . . . . . . . . . . . . . . . . . . . . 80065471
V
1
Electronic Ignition Kit . . . . . . . . . . . . . . 80008194
W
3
Carryover Tubes. . . . . . . . . . . . . . . . . . 80005592
X
5
Control Knobs. . . . . . . . . . . . . . . . . . . . 80011975
Y
5
Control Knob Bezels. . . . . . . . . . . . . . . 80005596
Z
1
Upper Back Panel . . . . . . . . . . . . . . . . 80013281
AA
1
Left Sideburner Shelf . . . . . . . . . . . . . . 80008181
BB
1
Fascia, Left Side Shelf . . . . . . . . . . . . . 80012882
CC
1
Sideburner Pan . . . . . . . . . . . . . . . . . . 80006588
DD
1
Sideburner Lid . . . . . . . . . . . . . . . . . . . 80008182
EE
1
Right Side Shelf . . . . . . . . . . . . . . . . . . 80005608
FF
1
Fascia, Right Side Shelf . . . . . . . . . . . . 80006591
GG
1
Sideburner Burner Kit. . . . . . . . . . . . . . 80013400
HH
1
Lid Assembly . . . . . . . . . . . . . . . . . . . . 80008183
II
1
Inner Insert, Lid Assembly . . . . . . . . . . 80008184
JJ1
1
Tube Handle. . . . . . . . . . . . . . . . . . . . . 80006637
JJ2
1
Right Handle End Cap . . . . . . . . . . . . . 80016298
JJ3
1
Left Handle Eng Cap . . . . . . . . . . . . . . 80016299
Key Qty Description
Part #
KK
1
Logo Plate
80005616
LL
1
Temperature Gauge
80006666
MM
1
Lid Assembly Hardware Pack. . . . . . . . 80004371
NN
1
Left Door Assembly . . . . . . . . . . . . . . . 80008186
OO
2
Door Handle . . . . . . . . . . . . . . . . . . . . . 80065506
PP
1
Right Door Assembly . . . . . . . . . . . . . . 80008187
4
Flame Tamers. . . . . . . . . . . . . . . . . . . . 80003332
RR
2
Cooking Grates . . . . . . . . . . . . . . . . . . 80065455
SS
1
Warming Rack . . . . . . . . . . . . . . . . . . . 80004050
TT
1
Sideburner Grate . . . . . . . . . . . . . . . . . 80006640
UU
1
Grease Tray w/ Handle. . . . . . . . . . . . . 80008970
VV
1
Sideburner Cap Clip . . . . . . . . . . . . . . . 80006265
Not Pictured
1
Replacement Flame Tamer
Support Pins . . . . . . . . . . . . . . . . . . . 80000020
1
Door Magnet Assembly . . . . . . . . . . . . 80008850
1
Caster Wrench . . . . . . . . . . . . . . . . . . . 80000283
1
Product Guide (English) . . . . . . . . . . . . 80065474
1
Product Guide (Spanish) . . . . . . . . . . . 80065475
1
Hardware Pack (for retailer store only). 80006535
1
Screw Nut Pack (for purchaser) . . . . . . 80008849
4
#8x3/8” Self-Tapping Screw
2
4mm Flat Washer
2
5mm Flat Washer
26 7mm Flat Washer
4
#8-32x3/8” Screw
2
#10-24x3/8” Screw
10 1/4-20x1/2” Screw
8
1/4-20x3/4” Screw
8
1/4-20x1½” Screw
4
4mm Lock Washer
2
5mm Lock Washer
26 7mm Lock Washer
2
#8-32 Hex Nut
Tools required for assembly:
Caster Wrench - Provided • Phillips screwdriver - Not provided
Estimated assembly time:
30-45 minutes
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
