Dell™ PowerEdge™

SC 1430 Systems

Information Update

Installing a Fourth Hard Drive

A fourth hard drive requires an optional hard-drive carrier with a cooling fan. Installation steps are
described in "Installing an Optional Fourth Hard Drive" in your

Hardware Owner’s Manual. When

performing this procedure, note the following additional information:

NOTE:

If a second processor is installed in your system, do not route the fan cable through the narrow space

between the air baffle and the processor heat sink. Open the processor access door on the air baffle and push
the fan cable underneath the heat sink fins to prevent damage to the cable.

System Messages

Table 1 provides an additional system message that your system may display on the screen.
See "System Messages" in your

Hardware Owner’s Manual for information about

other system messages.

Table 1.

System Messages

Message

Causes

Corrective Actions

The FBD link to the

following DIMM failed

to train: DIMM x

Faulty or improperly installed
memory module.

Ensure that only Dell-qualified memory
is used. Dell recommends purchasing
memory upgrade kits directly from
www.dell.com or your Dell sales agent
to ensure compatibility.

Reseat memory modules. See "Memory"
in your

Hardware Owner’s Manual.

If the problem persists, see
"Troubleshooting System Memory"
in your

Hardware Owner’s Manual.

October 2006
