Computer Base
Dell™ XPS™ M2010 Service Manual
Replacing the Computer Base
Replacing the Computer Base
The computer base includes cables for the microphone and the keyboard. If you need to replace the computer base, follow all the instructions for removing the
system board assembly (see
System Board Assembly ) and install all system components into the new computer base.
Back to Contents Page
CAUTION: Before you begin the following procedure, follow the safety instructions in the Product Information Guide.
NOTICE: To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of your
computer's electronic components. You can do so by touching an unpainted metal surface. If you leave the area, ground yourself again when you return
to the computer.
NOTICE: To help prevent damage to the system board, remove the main battery before working inside the computer.
