I n f o r m a t i o n U p d a t e

1-3

System Board Connectors for Memory Modules

See Figure 1-2 for the location and the updated description of the memory module
connectors on the system board.

For more information on system board connectors, see your Installation and Troubleshooting
Guide.

F i g u r e 1 - 2 .

S y s t e m B o a r d C o n n e c t o r s f o r M e m o r y M o d u l e s

BANK1_A connector

BANK1_B connector

BANK2_A connector

BANK2_B connector

BANK3_A connector

BANK3_B connector
