Rack-Installationsanleitung
Abbildung 1-8.
Installation der Zugentlastungsstrebe
1 Käfigmuttern (2)
2
Befestigungs-
schrauben (2)
3
Optionale Zugentlastungs-
strebe (für oberseitige
Verkabelung)
4 Standardposition für
Zugentlastungsstrebe
5
Rack-Stabilisator-
winkel
6
Untere Klemmmutter für
Rack-Stabilisatorwinkel
1
3
2
Rack-Rückseite
6
5
4
