Dell™ PowerEdge™
SC 430 Systems
Information Update
Memory Module Installation Guidelines
Table 1 updates Table 5-1 in the Dell™ PowerEdge™ SC430 Systems Installation
and Troubleshooting Guide.
Removing the Drive Guide Bracket Assembly
The following step replaces step 4 under "Removing a Hard Drive" in the "Installing SATA or SCSI
Hard Drives" section of the Installation and Troubleshooting Guide.
Push down, then inward on the tabs on each side of the removable drive guide bracket and slide the
guide bracket up and out of the drive bay.
Table 1. Memory Configuration Guidelines
Total Memory DIMM_1 DIMM_2 DIMM_3 DIMM_4
256 MB 256 MB none none none
512 MB 256 MB 256 MB none none
1 GB 256 MB 256 MB 256 MB 256 MB
1 GB 512 MB 512 MB none none
1.5 GB 512 MB 512 MB 256 MB 256 MB
2 GB 512 MB 512 MB 512 MB 512 MB
2 GB 1 GB 1 GB none none
3 GB 1 GB 1 GB 512 MB 512 MB
4 GB 1 GB 1 GB 1 GB 1 GB
June 2005
