Instalación del hardware
Ilustración 2-6.
Cableado de hasta cuatro hosts con rutas de datos no redundantes
Servidor host de un solo HBA
Servidor host de un solo HBA
Módulo 0 de controladora
RAID
Módulo de controladora RAID 1
Alojamiento RAID de MD3000
Alojamiento de expansión
MD1000
Alojamiento de expansión
MD1000
Servidor host de un solo HBA
Servidor host de un solo HBA
