8
Focus Adjustment / Throw Distance – The focus can be adjusted by turning
the wheel located at the front of the projector. The Projector is capable of the
following throw and focus distances:
Diagonal size Diagonal size Vertical size Horizontal size Throw distance
(inch) (mm) (mm) (mm) (mm)
30 762 457 610 1250
40 1016 610 813 1666
50 1270 762 1016 2083
60 1524 914 1219 2499
70 1778 1067 1422 2916
80 2032 1219 1626 3332
90 2286 1372 1829 3749
100 2540 1524 2032 4166
Focus Adjustment / Throw Distance – The focus can be adjusted by turning
the wheel located at the front of the projector. The Projector is capable of the
following throw and focus distances:
7
